PATTERN CAPABILITY METALLURGICAL LABORATORY
22 wax Injection Machines.
16 Mueller Phipps, side injection.
3 Mueller Phipps, automatic top injection.
2 Mueller Phipps, automatic wax/gate works stations.
1 Mueller Phipps 20-10 automatic gating.

2 Angstrom 950 spectrometers.
1 Leco carbon and sulfur determinator, CS 300.
1 Olympus PME microscope.
1 Leco M400 micro hardness tester.
SHELL BUILDING
(INVESTMENT)		 HEAT TREATING
Environmentally controlled and equipped ceramic shell-molding process, 1 hand dipping line operating two shifts plus 4 automatic lines utilizing robots. 4 electrical internal quench atmosphere furnaces; 600-lb. load.
Loading space 24” wide X 36” deep X 18” high.
4 Vacuum annealing furnaces for stainless steel – 2500-lb load.
1 electric salt-bath martempering and austempering heat treating system, fully automated.
4 tempering furnaces, 1 atmosphere, 1 vacuum.
FOUNDRY TOOL ROOM
3 350-Kilowatt induction melting units.
Total melting capacity 24 tons/day.		 CAD/CAM software: SolidWorks, ProCAM II.
8 Bridgeport millers with acu-rite mill power 2 axis control.
3 surface grinders.
1 lathe.
1 vertical band saw.
2 horizontal cut off saws.
1 3 axis CNC, Fadal EMC.
1 EDM.
Granite inspection plates.
FINISHING FLOOR SPACE
1 HAAS VF-2 Vertical milling.
1 HAAS VF-3 Vertical milling center with pallet changer.
Complete complement of gate cutting and grinding equipment, straightening presses, acid pickling, welding, grit blasting, drilling, and milling.		 105,000 square feet, plus 15,000 square feet of warehouse.
INSPECTION
TAQ 524 magnetic particle inspection unit (Magnaglo).
ZA28W fluorescent penetrant inspection station.
6 Rockwell hardness testers with printers.
1 DEA co-ordinate measuring machine, direct computer controlled and complete manual inspection capabilities
1 J&L optical comparator.
